Consumer HDMI content is now breaking through the once comfortable HDBaseT ‘ceiling’ of 10Gbps, with HFR (High Frame Rate) HDR here already in the form of Blu-Ray, Satellite & Cable (HLG) and gaming content. WyreStorm??s H2XC matrix platform is ready for this, with this receiver being the perfect match for the TX-H2X-VLC modular card, using our new light-compression transmission solution.
For use exclusively with H2XC matrix and TX-H2X-VLC modular card. Not compatible with MXV matrix range.
Reliable HDBaseT-HDMI conversion over distance using single Cat6 cable
4K UHD signals up to 70m/230ft (2160p 4:4:4 60Hz 8-bit) and 2K signals up to 140m/459ft (1200p 60Hz 16-bit)
Supports HDMI2.0 video standard up to 18Gbps
Compatible with HDR standards including HDR-10, HDR-10+, HLG and Dolby Vision (Dolby Vision supported up to 30Hz)
Class A HDBaseT supporting the transmission of video, multichannel audio, Ethernet, bidirectional control and PoH
Powered remotely via PoH from H2XC matrix
HDCP 2.2 compatible
Bidirectional IR supported with both IR TX & RX ports
RS-232 port for routed 2-way serial communication
Supports Ethernet pass-through from matrix (Class A HDBaseT transmission only)
LED indication for HDCP presence within signal and transmission link between devices
Ventilated steel chassis
Conforms to IEEE-568B standards
Compact design for convenient and unobtrusive installation
Wall mounting brackets and IR accessories included
