With support for 4K/HDR resolutions, HDCP 2.2, and HD multi-channel audio formats, this four-output splitter allows for simple, reliable distribution of a single HDMI source to multiple duplicate displays. Additionally, the compact chassis makes it perfect for environments where unobtrusive installation is important.
Splits a single HDMI 4K/HDR or 1080p HD device to four 4K/HDR or HD display devices
Supports resolutions up to 4K@60Hz, including 3840×2160 (HDR) and 4096×2160 (DCI) and 1920x1080p@60Hz
HDCP 2.2 supported
Color depth 24bit (4K) and 36bit (1080p) full 4K chroma subsampling color palette 4:4:4
3D compatible (up to 1080p)
DVI support up to 1920×1200
Multichannel Dolby and DTS HD audio supported up to 7.1 (mirrors source)
Extensive EDID management for improved compatibility and communication between connected source and display devices
Front panel LED indication for visual confirmation of I/O and power connectivity
Locking DC 12v power port
3-pin Phoenix connector for firmware updates
Transmission distance up to 10m/33ft (4K/1080p input, 4K output), 15m/49ft (1080p output) using standard high speed HDMI cables
Ultra-slim 18mm chassis design for space-saving local installation, surface mountable
Units cascadable to create larger systems
12v DC 1A power supply and mounting brackets included
